Printing

Printing Method

Direct Thermal

Resolution

203 dpi (8 dots/mm)

Printing Speed

2 ips ~ 4 ips

Printing Width

Max. 108 mm

Printing Length

15 mm ~ 300 mm

Memory

RAM

2 MB

Flash

2 MB

Sensors

Gap Sensor

Transmissive (Fixed, Center)

Black Mark Sensor

Reflective (Adjustable, Half-Range)

Other

Out of paper detection, Notch detection, TPH temperature detection

Media

Types

Fan-fed or Roll-fed, Die-cut or Continuous Label

Width

1"(25.4 mm) ~ 4.64"(118 mm)

Thickness

0.003"(60 μm) ~ 0.007"(180 μm)

Label Roll Diameter

127 mm

Core Diameter

1"(25.4 mm), 1.5"(38.1 mm)

Programming Language

TSPL



Software

Label Designer

Bartender Ultralite HPRT Spec. by Seagull

Driver

Windows XP/Vista/7/8/8.1/10

Fonts

Bitmap Fonts

6, 8, 12, 16, 32, OCR A & B. 90°, 180°, 270° rotatable and 10 times expandable in horizontal and vertical directions

Code Pages

PC437, 720, 737, 755, 775, 850, 852, 855, 856, 857, 858, 860, 862, 863, 864, 865, 866; Windows1250, 1251, 1252, 1253, 1254, 1255, 1256, 1257, 1258; ISO8859-1, 2, 3, 4, 5, 6, 8, 9, 15; DBCS 932 (JIS), 936(GBK), 949 (Koran), 950(BIG5)



Barcode

Linear Barcodes

CODE39, CODE93, EAN-8, EAN-13 (with EAN-2 or EAN-5 add-on), UPC-A, UPC-E

2D Barcodes

QR Code

Interfaces

Standard

USB Type B

Option

Serial Port and Ethernet

Control Panel

Power button, Feed button



Power Adapter

Power Input

AC 100 ~ 240V, 50/60Hz

Power Output

DC 24V, 2A

Environment

Operation

41 ℉ ~ 104 ℉ (5 ℃ ~ 40 ℃), 30% ~ 85%, no-condensing

Storage

-4 ℉ ~ 122 ℉ (-20 ℃ ~ 50 ℃), 10% ~ 50%, no-condensing

Physical Characteristics

Dimension

244(L)×205(H)×174(W) mm

Weight

1.5 kg

Options and Accessories

External label roll holder

OLED Display with Touch Panel



Agency Approvals

CCC, FCC, CE
